Product Description:
The JJD-5 Electric Motor Winch
The JJD-5 electric motor winch is a powerful and reliable winching
solution. Equipped with a 4KW motor, clutch, gearbox, brake, and
winch roller component, this machine is designed to handle heavy
loads with ease.
One of the best things about the JJD-5 is its ease of maintenance,
overhaul, and operation. Whether you're using it for industrial or
personal use, this winch is built to last and perform flawlessly
every time.
Features:
Our electric winch comes equipped with the reliable JJD-5 electric
motor with a powerful 4KW motor. With its reliable performance,
convenient operation, and easy maintenance, this engine is built to
last.
The winch's transmission and gear shift are powered by a triangle
belt transmission to the gear case. Control of the winch is done
through a clutch handle that regulates its work. With clutch
torque, a multistage gear output to winch roller is achieved,
allowing for smooth and efficient operation.
The gearbox's various parts make use of splash lubrication for
efficient lubrication. It is recommended to inject 3 liters of 10#
engine oil to the gear box label position before using a new
machine. Regular maintenance, including an oil change every six
months, will help ensure the winch stays in top condition.
| Item number | Model | Rotation direction | Gear | rotational speed () | Traction speed (m/min) | Tractive force (T) | Power (KW)
| Outline size (mm) | Weight (kg) |
| 09121 | JJQ-3Q 6HP Gasoline engine | corotation | Ⅰ Slow | 9.0 | 4.0 | 3.0 | 4.04 | 840x450x500 | 82 |
Ⅱ Fast | 16.0 | 6.6 | 1.8 | 780x450x500 | 85 |
| reversal | Reverse | 7.5 | 3.3 | No lifting |
| 09121A | JJC-30 170F Diesel engine | corotation | Ⅰ Slow | 11.5 | 5.0 | 3.0 | 2.94 | 840x600x500 | 108 |
Ⅱ Fast | 21.0 | 9.0 | 1.8 |
| reversal | Reverse | 10.0 | 4.5 | No lifting |
| 09121B | JJD-30 3KW Electromotor | corotation | Ⅰ Slow | 8.5 | 4.0 | 3.0 | 3.00 | 770x600x460 | 108 |
Ⅱ Fast | 10.5 | 6.5 | 1.8 |
| reversal | Reverse | 7.0 | 3.0 | No lifting |
| 09123 | JJQ-50 9HP Gasoline engine | corotation | Ⅰ Slow | 6.5 | 4.0 | 5.0 | 6.61 | 1000x550x520 | 135 |
Ⅱ Fast | 16.0 | 9.0 | 2.2 |
| reversal | Reverse | 7.0 | 4.0 | No lifting |
| 09123A | JJC-50 6.6HP Diesel engine | corotation | Ⅰ Slow | 8.0 | 4.5 | 5.0 | 4.41 | 1000x750x600 | 168 |
Ⅱ Fast | 19.0 | 11.0 | 2.3 |
| reversal | Reverse | 10.0 | 5.5 | No lifting |
| 09123B | JJD-50 4KW Electromotor | corotation | Ⅰ Slow | 5.5 | 3.5 | 5.0 | 4.00 | 1000x850x520 | 160 |
Ⅱ Fast | 14.0 | 8.0 | 3.0 |
| reversal | Reverse | 7.0 | 4.0 | No lifting |
Technical Parameters:
Product Features
Our product is designed with a compact structure and strong
maneuverability, ensuring easy movement even in tough terrain
conditions. Additionally, it has a small volume and lightweight
design, making it especially suitable for use in water and
mountainous regions.
Efficiency and Ease of Operation
Our product is designed with a focus on simplicity and high work
efficiency. With the use of this machine, field staff can be
minimized, labor intensity can be reduced, and working efficiency
can be improved.
Safety and Reliability
We take safety seriously and have designed our product to be safe
and reliable. Our native interlocking brake system ensures precise
positioning and lifting of heavy objects while preventing
accidents. It's an excellent choice for companies or individuals in
need of a reliable and safe construction tool.
Applications:
The Electric Capstan Winch is used in various industries such as
electric power transmission, power supply, post and
telecommunications engineering, mining, railway, etc. It is a tool
that is essential for setting up poles and towers, take-ups,
wiring, tight lines, cable traction, and handling.
One of the significant advantages of the electric capstan winch is
its reasonable structure. It is designed to operate simply, and its
safety and reliability make it stand out from other types of
winches.
The electric capstan winch is widely applied and is a necessary
tool for numerous industries. It's commonly used for
post-installation fittings, such as cable and line fittings, tower
fittings, and transformer fittings, among other uses.
Overall, the benefits of the electric capstan winch make it a
reliable and practical tool for various industries, making it a
popular choice.
Support and Services:
We offer:
- Expert product installation guidance and troubleshooting assistance
- Warranty coverage and repair services for any defects or
malfunctions
- Product maintenance advice and tips for optimal performance and
longevity
- Access to product manuals and documentation for easy reference
Our team of knowledgeable and friendly support staff are always
available to answer any questions or concerns you may have about
our Cable Winch Puller product.
