Product Description:
The JJD-5 electric motor winch is a high-performing machine
equipped with a powerful 4KW motor, clutch, gearbox, brake, and
winch roller component. This winch is designed to provide maximum
efficiency and reliability while maintaining ease of maintenance,
overhaul and operation.
The 4KW motor provides high power output which allows for the winch
to easily handle a variety of different loads. The clutch, gearbox,
and brake work together to effectively control the machine's
movements, providing maximum safety and stability during operation.
In addition to its exceptional performance capabilities, the JJD-5
electric motor winch is also built for easy maintenance. The winch
can be easily disassembled for quick and efficient inspection and
repair of its key components. Regular maintenance procedures can be
performed without the need for complex tools or equipment,
minimizing downtime and maximizing efficiency.
Overall, the JJD-5 electric motor winch is an ideal machine for a
wide range of applications due to its powerful and efficient
performance, superior safety features, and easy maintenance and
operation.
JJD-5 Electric Motor Winch
- Equipped with 4KW motor, clutch, gearbox, brake and winch roller
component
- Easy maintenance, overhaul and operation
The JJD-5 electric motor winch is a high-performing machine
equipped with a powerful 4KW motor, clutch, gearbox, brake, and
winch roller component...
In addition to its exceptional performance capabilities, the JJD-5
electric motor winch is also built for easy maintenance...
Overall, the JJD-5 electric motor winch is an ideal machine for a
wide range of applications...
| Item number | Model | Rotation direction | Gear | rotational speed () | Traction speed (m/min) | Tractive force (T) | Power (KW)
| Outline size (mm) | Weight (kg) |
| 09121 | JJQ-3Q 6HP Gasoline engine | corotation | Ⅰ Slow | 9.0 | 4.0 | 3.0 | 4.04 | 840x450x500 | 82 |
Ⅱ Fast | 16.0 | 6.6 | 1.8 | 780x450x500 | 85 |
| reversal | Reverse | 7.5 | 3.3 | No lifting |
| 09121A | JJC-30 170F Diesel engine | corotation | Ⅰ Slow | 11.5 | 5.0 | 3.0 | 2.94 | 840x600x500 | 108 |
Ⅱ Fast | 21.0 | 9.0 | 1.8 |
| reversal | Reverse | 10.0 | 4.5 | No lifting |
| 09121B | JJD-30 3KW Electromotor | corotation | Ⅰ Slow | 8.5 | 4.0 | 3.0 | 3.00 | 770x600x460 | 108 |
Ⅱ Fast | 10.5 | 6.5 | 1.8 |
| reversal | Reverse | 7.0 | 3.0 | No lifting |
| 09123 | JJQ-50 9HP Gasoline engine | corotation | Ⅰ Slow | 6.5 | 4.0 | 5.0 | 6.61 | 1000x550x520 | 135 |
Ⅱ Fast | 16.0 | 9.0 | 2.2 |
| reversal | Reverse | 7.0 | 4.0 | No lifting |
| 09123A | JJC-50 6.6HP Diesel engine | corotation | Ⅰ Slow | 8.0 | 4.5 | 5.0 | 4.41 | 1000x750x600 | 168 |
Ⅱ Fast | 19.0 | 11.0 | 2.3 |
| reversal | Reverse | 10.0 | 5.5 | No lifting |
| 09123B | JJD-50 4KW Electromotor | corotation | Ⅰ Slow | 5.5 | 3.5 | 5.0 | 4.00 | 1000x850x520 | 160 |
Ⅱ Fast | 14.0 | 8.0 | 3.0 |
| reversal | Reverse | 7.0 | 4.0 | No lifting |
Features:
Here are some improved paragraphs for the given text formatted in
HTML:
Engine: The JJD-5 electric motor winch is equipped with a 4KW motor
providing reliable performance, convenient operation, and
maintenance.
Transmission and Gear Shift: The winch is powered by a triangle belt transmission that delivers
power to the gear case. The winch operation is controlled by a
clutch handle. The clutch torque provides multistage gear output to
the winch roller.
Lubrication: The gearbox of various parts depends on splash lubrication. Before
using a new machine, 3 liters of 10# engine oil must be injected
into the gear box label position. Regular maintenance requires
changing the oil every six months or when needed.
Technical Parameters:
Product features:
The following are the features of our product:
1. Compact structure, strong maneuverability.
The product has a compact structure which allows it to have strong
maneuverability. This means that it can be easily moved around and
navigated through tight spaces or complex terrain with ease.
2. Small volume, light weight. Especially suitable for water,
mountains, and the complex terrain conditions construction use.
The product is designed to be small and lightweight compared to
other similar products in the market. This makes it especially
suitable for use in construction sites that have complex terrain
conditions, such as water and mountains. Its small size and
lightweight make it easily transportable to different sites.
3. Simple operation, high work efficiency.
Our product is designed with user-friendliness in mind. It has a
simple operation system that is easy to use, even for those who are
not experienced. With this machine, a maximum reduction in field
staff can be achieved, reducing labor intensity and improving the
work efficiency of the work site.
4. Safe and reliable. Native unique interlocking brake brakes,
brake, precision positioning, to ensure lifting heavy things hover
at any location.
The product has been designed with safety as a top priority. It has
native unique interlocking brakes that ensure the precise
positioning of the product, enabling heavy things to be lifted and
hover at any location. This provides a safe and reliable experience
for the user.
Applications:
The Electric Capstan Winch has become one of the most popular
equipment in various industries across the world due to its
reasonable structure, simple operation, safety, reliability, and
other significant advantages.
The equipment is widely applied in the electric power transmission,
power supply and post and telecommunications engineering, mining,
railway, and other industries. It is known to be an essential tool
for setting up poles and towers, take-up, wiring, tight line, cable
traction, and handling.
Support and Services:
Our team of expert technicians is available to provide assistance
with installation, operation, and maintenance of the winch puller.
We offer phone and email support during regular business hours, and
also have an online knowledge base with frequently asked questions
and troubleshooting guides.
In addition to technical support, we also offer repair and
maintenance services to help keep your winch puller in top working
condition. Our technicians are trained to diagnose and fix any
issues with your winch puller, and we offer both on-site and
off-site repairs, depending on your needs.
Finally, we offer training services to ensure that your staff is
fully equipped to operate the winch puller safely and effectively.
Our training sessions cover everything from basic operation to more
advanced techniques, and can be customized to meet your specific
needs and equipment.
