Product Description:
This manual provides essential information on how to properly
operate and maintain the diesel engine powered winch. It is
important to adhere to these instructions in order to achieve
optimal performance and ensure that the machine is functioning
correctly.
While we are committed to constantly improving our products, please
be aware that materials and specifications may be subject to change
without notice or obligation. As such, it is important to stay
updated with any potential changes that may impact the use or
maintenance of your winch.
| Item number | 09162B | 09154 | 09162 |
| Model | JJCS-50J | JJQS-50J | JJCS-50T |
| Engine | Model | KF186FA Diesel Engine | Honda 390 Gasoline Engine | S195G Diesel Engine |
| Power(KW) | 6.3 | 6.6 | 9 |
| Speed(rpm) | 2600 | 3600 | 2000 |
Pull force(KN)/ speed (m/Min) | Slow | 50/6 30/10 | 50/6 30/10 | 50/3.1,40/9.6 |
| Moderate | / | / | 45/7.1 17/22.3 |
| Fast | 13/23 10/30 | 13/23 10/30 | 33/11.3 10/35.6 |
| Reverse | -/5 -/17 | -/5 -/17 | -/7.35 |
| Drum bottom of groove diamete(mm) | Φ230 | Φ230 | Φ300 |
| Outline size (mm) | 1280x770x600 | 1280x770x600 | 2440x1300x1140 |
| Weight(kg) | 280 | 270 | 700 |
Features:
The JJCS 50 Diesel Engine Double Drum Winch Trailer is a
specialized piece of equipment designed to handle heavy-duty
lifting and towing. Anyone who requires a reliable trailer that
goes the distance and handles the most demanding tasks could
utilize this specialized equipment. The following are some
essential features and characteristics you should be aware of:
Key Features:
- Double Drum Design: This feature enables the pulling or lifting of heavy loads to be
performed with more considerable efficiency by allowing for
simultaneous operation.
- Diesel Engine: The trailer comes with a diesel engine that ensures reliable
performance in varying conditions. It provides robust power for the
trailers' demanding applications, allowing it to be used for long
periods.
- Trailer Mounted: This feature enhances mobility, allowing for easy transport to
different job sites. The helps ensure that it is always ready for
the user to utilize due to its ease of transportation and
accessibility.
- High Load Capacity: The trailer is capable of handling considerable weights, making it
ideal for various tasks. Examples of such operations include
construction, logging, and marine applications.
- Durable Construction: The trailer is built with high-strength materials, making it
incredibly sturdy to withstand harsh environments and heavy usage.
This construction helps in ensuring that the equipment remains
useful and reliable over the long term.
Technical Parameters:
A double drum winch is a versatile machine that finds application
in many areas such as power transmission and distribution
engineering, telephone construction tower erection, and hoisting
tools. It can be used for traction cable, line, tower erection,
pole setting, and stringing wire in electrical power line
construction. This machine is driven by a belt which prevents
overload damages effectively.
The double drum structure of the winch reduces wire rope damages
during traction. The machine can be powered by either diesel or
gasoline power as demanded by the user. The jjcs-50t model of
double drum winch is equipped with at least 6 traction gears.
Different traction forces correspond to different traction speeds.
The winch's rack can be installed on a trailer to enable easy
transportation.
The Uses of Double Drum Winch
- Power transmission and distribution engineering
- Telephone construction tower erection
- Traction cable and line
- Hoisting tools
- Tower erection and pole setting
- Stringing wire in electrical power line construction
Winch Specifications
| Features | Specifications |
|---|
| Structure | Double drum |
| Power Source | Diesel power or gasoline power |
| Model | jjcs-50t |
| Traction gears | Up to 6 |
| Traction speed | Depends on the traction force and gear |
| Rack | Installed on a trailer for easy transport |
Applications:
Applications
The JJCS 50 Diesel Engine Double Drum Winch Trailer is a versatile
and efficient tool in various construction and maintenance
scenarios. This winch trailer is designed to facilitate power
transmission and distribution engineering, telephone construction
and tower erection, traction cable and line installation, hoisting,
and pole setting tasks.
For power transmission and distribution engineering, the winch
trailer helps in laying and stringing conductors, installing wires,
and other tasks related to setting up a power distribution network.
Telephone construction and tower erection also require efficient
and safe tools to lift and install poles, towers, and other
components. The JJCS 50 Diesel Engine Double Drum Winch Trailer's
mobility and high load-carrying capacity provides a reliable
solution, resulting in faster and safer execution.
Traction cable and line installation is another challenging task
that requires careful planning and the right equipment. The winch
trailer is designed to carry heavy loads, making it ideal for
hauling electric cables, wires, and other heavy equipment. Hoisting
and pole setting tasks are also simplified with the JJCS 50 Diesel
Engine Double Drum Winch Trailer, allowing for quick installation
of poles and other structures.
Overall, the JJCS 50 Diesel Engine Double Drum Winch Trailer is a
valuable tool in various construction and maintenance scenarios.
Its design features are tailored to meet the demands of different
tasks, improving efficiency and safety while reducing the risk of
work injuries and accidents.
