Product Description:
A powered diesel winch is a strong and reliable mechanical device
that is specifically designed to handle heavy-duty lifting and
pulling operations. What sets it apart from other winches is its
diesel engine power source, which makes it extremely versatile and
ideal for a variety of industrial applications.
The winch comes in two different models: the belt type and the
shaft-driven type. Both of these models are perfectly suitable for
construction of the tower line, traction line, tight line
operation, and laying cables.
The belt-driven model is primarily designed for laying cables
underground. It comes equipped with four gear boxes and is great
for pulling heavy loads over long distances. The shaft-driven
model, on the other hand, is better suited for overhead line
applications. It features six gear boxes and can pull loads at a
faster rate than the belt type. However, it is also more expensive
than the belt type.
Fast powered shaft driven winch data sheet.
| Item number | Model | Rotation direction | Gear | Tractive force (T) | Traction speed (M/MIN) | Power (KW) | Outline size (MM) | Weight (KG) |
| 09131 | JJQ-30 6HP Gasoline engine | corotation | SlowⅠ | 3.0 | 5 | 4.04 | 900x400x430 | 94 |
| SlowⅡ | 2.0 | 7 |
| FastⅠ | 0.9 | 16 |
| FastⅡ | 0.6 | 24 |
| reversal | Slow | No lifting | 4 |
| Fast | 13 |
| 09131A | JJC-3 5HP Diesel engine | corotation | SlowⅠ | 3.0 | 5 | 2.90 | 1000x450x500 | 115 |
| SlowⅡ | 2.0 | 7 |
| FastⅠ | 0.9 | 16 |
| FastⅡ | 0.6 | 24 |
| reversal | Slow | No lifting | 4 |
| Fast | 13 |
| 09135 | JJQ-5B 9HP Gasoline engine | corotation | FastⅠ | 0.9 | 24 | 6.6 | 1100x525x600 | 138 |
| FastⅡ | 1.5 | 13 |
| SlowⅠ | 2.5 | 8 |
| SlowⅡ | 5.0 | 4 |
| reversal | Slow | No lifting | 4 |
| Fast | 18 |
| 09135A | JJC-5B 186F Diesel engine | corotation | FastⅠ | 0.9 | 24 | 5.7 | 1000x498x600 | 148 |
| FastⅡ | 1.5 | 13 |
| lowⅠ | 2.5 | 8 |
| SlowⅡ | 5.0 | 4 |
| reversal | Slow | No lifting | 4 |
| Slow | 18 |
Belt driven transmission line pulling winches
| Item number | Model | Rotation direction | Gear | rotational speed () | Traction speed (m/min) | Tractive force (T) | Power (KW)
| Outline size (mm) | Weight (kg) |
| 09121 | JJQ-3Q 6HP Gasoline engine | corotation | Ⅰ Slow | 9.0 | 4.0 | 3.0 | 4.04 | 840x450x500 | 82 |
Ⅱ Fast | 16.0 | 6.6 | 1.8 | 780x450x500 | 85 |
| reversal | Reverse | 7.5 | 3.3 | No lifting |
| 09121A | JJC-30 170F Diesel engine | corotation | Ⅰ Slow | 11.5 | 5.0 | 3.0 | 2.94 | 840x600x500 | 108 |
Ⅱ Fast | 21.0 | 9.0 | 1.8 |
| reversal | Reverse | 10.0 | 4.5 | No lifting |
| 09121B | JJD-30 3KW Electromotor | corotation | Ⅰ Slow | 8.5 | 4.0 | 3.0 | 3.00 | 770x600x460 | 108 |
Ⅱ Fast | 10.5 | 6.5 | 1.8 |
| reversal | Reverse | 7.0 | 3.0 | No lifting |
| 09123 | JJQ-50 9HP Gasoline engine | corotation | Ⅰ Slow | 6.5 | 4.0 | 5.0 | 6.61 | 1000x550x520 | 135 |
Ⅱ Fast | 16.0 | 9.0 | 2.2 |
| reversal | Reverse | 7.0 | 4.0 | No lifting |
| 09123A | JJC-50 6.6HP Diesel engine | corotation | Ⅰ Slow | 8.0 | 4.5 | 5.0 | 4.41 | 1000x750x600 | 168 |
Ⅱ Fast | 19.0 | 11.0 | 2.3 |
| reversal | Reverse | 10.0 | 5.5 | No lifting |
| 09123B | JJD-50 4KW Electromotor | corotation | Ⅰ Slow | 5.5 | 3.5 | 5.0 | 4.00 | 1000x850x520 | 160 |
Ⅱ Fast | 14.0 | 8.0 | 3.0 |
| reversal | Reverse | 7.0 | 4.0 | No lifting |
| 09125 | JJQ-80 13HP Gasoline engine | corotation | Ⅰ Slow | 5 | 3 | 8 | 9.60 | 1000x550x520 | 168 |
Ⅱ Fast | 9 | 5 | 4.5 |
| reversal | Reverse | 5 | 3 | No lifting |
| 09125A | JJC-80 10.5HP Diesel engine | corotation | Ⅰ Slow | 7 | 4 | 8 |
7.86 | 1000x750x630 | 230 |
Ⅱ Fast | 13 | 7.5 | 4 |
| reversal | Reverse | 6.5 | 3.7 | No lifting |
Applications:
Main Applications:
- Construction
- Mining
- Forestry
- Marine operations
- Oil and gas industry
Considerations:
When selecting a powered diesel winch, there are several factors
that need to be taken into consideration. Firstly, regular
maintenance is required to ensure its optimal function. Secondly,
the emissions and noise levels produced by diesel winches should be
carefully considered, particularly in areas where noise pollution
is highly regulated. Lastly, the initial cost of diesel winches is
generally higher compared to electric winches. However, diesel
winches are often more powerful in terms of pulling capacity.
Other factors that should be taken into account include the length
of the rope and the environmental conditions under which the winch
will be operated. Factors such as temperature, humidity and
altitude can all have an impact on the performance of a diesel
winch.
Support and Services:
We also offer repair and replacement services in the unlikely event
that your Cable Winch Puller is damaged or malfunctions. Our
technicians are trained to quickly diagnose and resolve any issues,
and we use only genuine parts to ensure your product operates at
peak performance.
Additionally, we provide ongoing support through our customer
service hotline and online resources, such as user manuals and
instructional videos. Our goal is to ensure that you have a
positive experience with your Cable Winch Puller and that it
continues to meet your needs for years to come.
Packing and Shipping:
Product Packaging:
- One Cable Winch Puller
- Two Heavy Duty Steel Cables
- Instruction Manual
Shipping:
- Ships within 24 hours
- Free Shipping
- Tracking number provided
- Delivery time: 3-5 business days
