Product Description:
The Main Structure of Anti Twist Steel Wire Rope
Anti Twist steel wire rope is composed of multiple strands of steel
wire rope wound to form a strong and resilient structure. At the
core of the steel wire rope, a specially designed steel core is
also wound to provide additional strength and stability. This
unique design effectively prevents twisting deformation and ensures
that the wire rope remains durable and reliable for a long time.
Characteristics of Anti Twist Steel Wire Rope
One of the key characteristics of Anti Twist steel wire rope is its
resistance to fatigue. Despite frequent use and exposure to harsh
environmental conditions, this type of wire rope is able to
withstand significant wear and tear without losing its strength or
integrity.
In addition, Anti Twist steel wire rope is also known for its high
tensile strength. This means that it can support heavy loads and
withstand significant pressure without breaking or deforming.
Furthermore, its long service life makes it a cost-effective option
for a wide range of applications.
Despite its strength and durability, Anti Twist steel wire rope
also has good flexibility, allowing it to bend and adapt to
different shapes and structures. This flexibility is key for many
applications, as it allows the wire rope to be used in a variety of
different settings and configurations.
Overall, Anti Twist steel wire rope is a rugged and reliable option
for a variety of different industrial and commercial applications.
Whether you need to lift heavy loads, support structures, or secure
equipment, this type of wire rope is sure to meet your needs.
12 Strands Anti twisting braided steel wire rope
| Item No. | Nominal diameter | Breaking Load (KN) | Single strand diameter (mm) | Normal T/S (N/mm²) | Net Weight (kg/1000m) |
| 18201A | 9mm | 50 kN | 2.0mm | 1960 | 250 |
| 18202A | 10mm | 70 kN | 2.3mm | 1960 | 356 |
| 18203A | 11 mm | 85 kN | 2.5mm | 1960 | 410 |
| 18204A | 12 mm | 100 kN | 2.7mm | 1960 | 510 |
| 18205A | 13 mm | 115 kN | 3.0mm | 1960 | 620 |
| 18206A | 14 mm | 130 kN | 3.2mm | 1960 | 710 |
| 18207A | 15mm | 143 kN | 3.3mm | 1960 | 770 |
| 18208A | 16mm | 160 kN | 3.5mm | 1960 | 800 |
| 18209A | 18mm | 206 kN | 4.0mm | 1960 | 1060 |
| 18210A | 19mm | 236 kN | 4.3mm | 1960 | 1210 |
Applications:
The Anti-twisting braided steel wire rope is designed to be applied
to mechanical pulling and tension release conductors. It is used to
exert pulling force or function as a leading rope.
The Anti-Twist steel wire rope is highly suitable for pulling a
single conductor or OPGW on the overhead transmission line. It can
also be used on super-high transmission lines for pulling bigger
conductors. Its exceptional qualities make it the ideal choice for
efficient overhead transmission line stringing work.
Customization:
Model Number: Anti-twist steel wire rope
Place of Origin: Ningbo China
Certification: ISO CE
Minimum Order Quantity: 2000m
Price: get the latest
Packaging Details: Drum, reel
Delivery Time: 7-10 days
Payment Terms: T/T
Supply Ability: 200 KM PER MONTH
Type: With Brake
Certifications: ISO 9001, CE
Number Of Strands: 12 Or 8
Usage: Lifting, Rigging, Towing
Galvanization: Hot Dipped Galvanization
Product Customization Services:
- Anti Twist Steel Wire Rope 20mm for pulling four Bundled Conductors
on transmission line
- Anti Twist Wire Rope 24MM for stringing 6 conductors
- 22mm Anti Twisting Pilot Wire Rope for stringing four Conductors on
Support and Services:
The Anti Twist Steel Rope is designed with special technology to
prevent twisting and tangling during use. Our team of technical
support experts is available to assist with any product questions
or issues you may encounter. We also offer a range of services to
ensure your rope performs at its best, including maintenance and
repair, custom length cutting, and splicing. Contact us to learn
more about our technical support and services.
FAQ:
Q: What is the brand name of the product?
A: The brand name of the product is Lingkai.
Q: What is the model number of the product?
A: The model number of the product is Anti-twist steel wire rope.
Q: Where is the product manufactured?
A: The product is manufactured in Ningbo, China.
Q: What certifications does the product have?
A: The product has ISO and CE certifications.
Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 2000m.
Q: What is the price of the product?
A: Please contact us to get the latest price.
Q: What are the packaging details for the product?
A: The product can be packaged in a drum or reel.
Q: What is the delivery time for the product?
A: The delivery time for the product is 7-10 days.
Q: What are the payment terms for the product?
A: The payment terms for the product are T/T.
Q: What is the supply ability of the product?
A: The supply ability of the product is 200 KM per month.
