Aluminum Alloy Working Platform For Compression Of Conductor Joints On Tower

Working Platforms are used for conductor compression and sagging on tower. They are made of aluminum alloy, can be assembled with different length. The whole equipment include accessories wire ropes and connection parts.

Frame Style Working Platform (Aluminum alloy)

Item No.: 22251

Technical data:

- Rated load (KN): 1.5

- Length (m): 4

- Hoisting points: 4

Application: Used on strain poles for clipping-in conductors or aerial compression joining operations etc.

Section dimension (mm): 350 x 450

Weight (kg): 32

Note: More load required, more suspension ropes are needed. The platform should be tested before use.

Aluminium Alloy Working Platform KL16m

Item No.: 22252

Technical data:

- Rated load (KN): 3

- Length (m): 16 (4+4+4+4)

- Hoisting points: 5

Application: It is used on tower for clipping-in conductors or aerial compression joining operations etc.

Section dimension (mm): 350 x 450

Weight (kg): 192

Note: More load required, more suspension ropes are needed. The platform should be tested before use.
