Product Description:
Tower Erection Tools Gin Pole are customized in terms of section
and length based on the tower height, tower weight, and tower type
for manufacturing by Ningbo lingkai. There are various types
available, including the aluminum alloy inner suspended gin pole,
aluminum alloy inner suspended lattice gin pole, aluminum alloy
lattice gin pole, and A-shape tubular gin pole, among others.
Furthermore, the aluminum alloy used in these gin poles is all of
the highest quality 2A12 grade, rather than LY 12 material. This
choice is made to increase the safety factor to over 3.0 and
provide greater strength against axial and vertical loads.
Aluminum alloy inner-suspension type gin pole (Lattice)
| Item No. | Overall Length (m) | Side Length of Cross Section (mm) | Allowed Axial Load (KN) | Weight (kg/m) |
| 03121 | 10 | 250 | 23 | 10.5 |
| 03123 | 12 | 16 |
| 03124 | 13 | 13 |
| 03125 | 14 | 11 |
| 03126 | 15 | 10 |
| 03131 | 11 | 300 | 29 | 11 |
| 03132 | 12 | 24 |
| 03134 | 14 | 18 |
| 03136 | 16 | 13 |
| 03138 | 18 | 11 |
| 03142 | 12 | 350 | 33 | 13.5 |
| 03144 | 14 | 24 |
| 03146 | 16 | 19 |
| 03148 | 18 | 15 |
| 03151 | 12 | 400 | 43 | 14.6 |
| 03153 | 14 | 32 |
| 03155 | 16 | 25 |
| 03157 | 18 | 19 |
| 03159 | 20 | 14 |
| 03511 | 14 | 500A | 75 | 18 |
| 03513 | 16 | 64 |
| 03515 | 18 | 50 |
| 03517 | 20 | 41 |
| 03521 | 17 | 500B | 88 | 22 |
| 03523 | 19 | 70 |
| 03525 | 21 | 60 |
| 03527 | 23 | 52 |
| 03529 | 25 | 42 |
| 03531 | 17 | 600A | 75 | 20 |
| 03533 | 19 | 65 |
| 03535 | 21 | 55 |
| 03537 | 23 | 49 |
| 03539 | 25 | 41 |
| 03541 | 17 | 600B | 119 | 24 |
| 03543 | 19 | 104 |
| 03545 | 21 | 85 |
| 03547 | 23 | 70 |
| 03549 | 25 | 58 |
Application: It is used to assemble and erect tower in power
transmission line construction. The gin poles are made in aluminum
alloy and could be assembled piece by piece. There are a few kinds
of heads and bottoms to be selected according to customer's
requirement
Features:
The Tower Erection Tools Gin Pole plays a crucial role in the
smooth and secure assembly of towers for a wide range of
construction and telecommunications projects. Meticulously crafted
from premium quality materials, this gin pole stands out for its
exceptional strength and stability, guaranteeing resilience against
the demanding tasks of heavy lifting and precise positioning.
One of the standout features of this innovative gin pole is its
adjustable height settings, providing flexibility to accommodate
various tower configurations. Alongside this, its integrated pulley
system significantly boosts lifting capabilities, simplifying the
process of positioning hefty components accurately.
In terms of safety, the gin pole comes equipped with a range of
protective elements like locking mechanisms and reinforced
attachment points, offering operators reassurance and confidence
throughout its use. Whether you're engaged in the construction of a
telecommunications tower, wind turbine, or any other tall
structure, the Tower Erection Tools Gin Pole serves as a trusted
companion, ensuring both accuracy and safety in tower erection
tasks.
Applications:
Max. Length of gin pole: 25 Meters
Inner-suspended lattice gin pole, Inner suspended lattice gin
poles, Aluminum alloy A-shape tubular gin pole suppliers
