Product Description:
Mesh socket joints are utilized for the pulling of overhead conductors, OPGW, and
earth wires, as well as underground power cables or
telecommunication optic fiber cables. These sockets are constructed
from high-strength galvanized steel wire and are tailored to the
specifications of various cables.
The head-type and double head-type temporary mesh sock joints are uniquely engineered for the
temporary linkage between aluminum-steel or copper conductors and
the pulling rope.
Features:
The product is constructed using high-grade steel that has
undergone heat treatment and galvanizing for surface protection.
It is designed to connect two components: one end features a
galvanized steel wire rope, while the other end connects to the
conductor.
Technical Parameters:
The mesh sock joints are specifically designed for pulling or installation of OPGW
cable or GSW cable in transmission line stringing operation. It is
braided from high strength galvanized steel wire. They consist of
variable pitch steel wires, which effectively distribute the
gripping effect on the OPGW wire or earth wire.
The Temporary Mesh Sock Joints length is 1.2m, it is used to hold OPGW or Earth Wire. The pulling
grips are specially braided from high strength galvanized steel
wire strands. It can hold the OPGW tightly and protect the surface
of OPGW well.
MESH SOCKET JOINTS FOR OPGW AND EARTH WIRE
| Single head Item No. | Double head Item No. | Model | Cable Diameter (mm) | Load (KN) |
| With protector | w/ protector | Rated | Break |
| 17141 | 17141S | SLE(S)-1 | Φ 7-11 | 10 | 30 |
| 17142 | 17142S | SLE(S)-1.5 | Φ 11-15 | 15 | 45 |
| 17143 | 17143S | SLE(S)-2 | Φ 15-18 | 20 | 60 |
| 17144 | 17144S | SLE(S)-2.5 | Φ 18-22 | 25 | 75 |
Applications:
Application: OPGW Socket Joints
OPGW Socket Joints are designed for gripping OPGW or GSW during
line stringing operations. These products are specially crafted
from high-strength galvanized steel wire, ensuring durability and
reliability. They are capable of smoothly passing through stringing
blocks and tension wheels.
Mesh Socket Joints Features
The Mesh Socket Joints are constructed using high-strength
galvanized steel wire that is intricately braided in a soft manner.
They are further enhanced with protective aluminum sleeves and
copper sleeves. These sleeves serve to shield the conductor and
prevent the OPGW head from causing damage to the Mesh Socket
Joints.
Customization:
Product Customization Services for the OPGW Installation Tools
Brand Name: NBLK
Model Number: SLE(S) ,SLE
Place of Origin: NINGBO CHINA
Certification: ISO CE
Minimum Order Quantity: 10
Price: Get the latest
Packaging Details: Wooden case packed
Delivery Time: 3-7days
Payment Terms: T/T
Supply Ability: 4000 sets/month
Packing type : Wooden Case
Working load (KN): Max 75KN
Model: SLE,SLE(S)
Name: OPGW Socket Pulling Grips
OPGW Diameter: 7-22mm, Or Customized
