Product Description:
Mesh socket joints are utilized to pull overhead conductor, OPGW, earth wires, or
underground power cable and telecom optic fiber cable. These socks
are woven from high-strength galvanized steel wire and are tailored
to various cable specifications.
The head-type and double head-type temporary mesh sock joints are intricately crafted to facilitate
the temporary connection of aluminum steel or copper conductors to
the pulling rope.
Features:
It is manufactured from high-quality steel that has undergone heat
treatment and galvanization for surface protection.
The connection involves two ends: one end is a galvanized steel
wire rope, and the other end connects to the conductor.
Technical Parameters:
The mesh sock joints are specially designed to be used in the
pulling or installation of OPGW cable or GSW cable during
transmission line stringing operations. These joints are braided
from high strength galvanized steel wire, and consist of variable
pitch steel wires that effectively distribute gripping force on the
OPGW wire or earth wire.
The Temporary Mesh Sock Joints have a length of 1.2m, and are
utilized to secure OPGW or Earth Wire. The pulling grips are
specifically braided from high strength galvanized steel wire
strands. They can securely hold the OPGW in place and provide
protection for its surface.
MESH SOCKET JOINTS FOR OPGW AND EARTH WIRE
| Single head Item No. | Double head Item No. | Model | Cable Diameter (mm) | Load (KN) |
| With protector | w/ protector | Rated | Break |
| 17141 | 17141S | SLE(S)-1 | Φ 7-11 | 10 | 30 |
| 17142 | 17142S | SLE(S)-1.5 | Φ 11-15 | 15 | 45 |
| 17143 | 17143S | SLE(S)-2 | Φ 15-18 | 20 | 60 |
| 17144 | 17144S | SLE(S)-2.5 | Φ 18-22 | 25 | 75 |
Applications:
Application of OPGW Socket Joints
The OPGW Socket Joints are designed for gripping OPGW or GSW during
line stringing operations. These products are crafted from
high-strength galvanized steel wire, ensuring durability and
reliability. They are specially braided to easily pass through
stringing blocks and tension wheels, facilitating smooth operation.
Features of Mesh Socket Joints
The Mesh Socket Joints are constructed from high-strength
galvanized steel wire, intricately braided to provide flexibility
and strength. They are further enhanced with protective aluminum
sleeves and copper sleeves. These sleeves play a crucial role in
safeguarding the conductor and preventing damage to the Mesh Socket
Joints caused by the OPGW head.
Customization:
Product Customization Services:
Brand Name: NBLK
Model Number: SLE(S), SLE
Place of Origin: NINGBO CHINA
Certification: ISO CE
Minimum Order Quantity: 10
Price: Get the latest
Packaging Details: Wooden case packed
Delivery Time: 3-7 days
Payment Terms: T/T
Supply Ability: 4000 sets/month
Working load (KN): Max 75KN
OPGW Diameter: 7-22mm, Or Customized
Application: OPGW Stringing Operations
Name: OPGW Socket Pulling Grips
Model: SLE, SLE(S)
