Manual Hand Lever Chain Lifting Block Hoist Overhead Line Stringing
Equipment Accessories
Product Description
Ratchet Leave Chain Hoists are used for lifting and sagging
operation in the transmission line stringing project. The Hoists
are equipped with safety device.
1. Rated Load: 5~200kN
2. Chains Length: 2.5~12m
3. Steel Made
4. Min. distance between hooks: 280~1040mm
5. The lifting hoists are made of steel and equipped with
mechanical brake; they are designed to facilitate and accelerate
chain positioning operations.
Applicatoin Apply to lifting parts and traction. Tigntening steel
stranded wire, aluminum stranded wire and kind wires.
Ratchet Lever Hoist with Chain
| MODEL | HSH-CII1.5 | HSH-CII3 | HSH-CII6 |
| Item No. | 14222 | 14232 | 14242 |
| CAPACITY (TONS) | 1.5 | 3 | 6 |
| STANDARD LIFT (M) | 3 | 3 | 3 |
| RUNNING TEST LOAD (KN) | 22.5 | 37.5 | 75.0 |
| EFFORT REQUIRED TO LIFT RATED LOAD (N) | 220 | 320 | 340 |
| STRAND NO. OF LOAD CHAIN | 1 | 1 | 2 |
| LOAD CHAIN DIAMETER (MM) | 8 | 10 | 10 |
| DIMENSIONS (MM) | A | 203 | 215 | 200 |
| B | 118 | 130 | 130 |
| C | 155 | 200 | 200 |
| D | 45 | 50 | 64 |
| H | 380 | 480 | 600 |
| L | 370 | 410 | 410 |
| K | 36 | 40 | 50 |
| NET WEIGHT (KG) | 11.8 | 21 | 32 |
| PACK MEASUREMENT (MM) | 46.5X15.5X19 | 51X19X21.5 | 53X22X21.5 |
| EXTRA WEIGHT OF PER METER | 1.4 | | 4.4 |
Application: It is used to lift goods or pulling the conductors
during the sagging operation.
Features:
1. Solid Bearing is adopted in the joint of load sprocket wheel and
wall panel, to improve the flexibility and working efficiency.
2. Needle bearing is adopted in the joint of major axis and load
sprocket wheel, to improve the flexibility and working efficiency.
3. The bottom hook can swivel 360 degrees freely under load.
4. Unique Overload Protection: Uni-directional free wheel device to
ensure the smooth descent of the hoist.
Hand Operated Chain Hoists
| Item No. | Chain length 1.5m | 14191 | 14201 | 14211 | 14221 | 14231 | 14241 |
| Chain length 3m | 14192 | 14202 | 14212 | 14222 | 14232 | 14242 |
| Chain length 4m | 14193 | 14203 | 14213 | 14223 | 14233 | 14243 |
| Chain length 5m | 14194 | 14204 | 14214 | 14224 | 14234 | 14244 |
| Model HSH-CII | 0.25 | 0.5 | 0.75 | 1.5 | 3 | 6 |
| Rated Load (KN) | 2.5 | 5 | 7.5 | 15 | 30 | 60 |
Application: It is used with conductor grips to tension conductors.
Chain Hoists
| Item No. | Chain length 2.5 m | 14281 | 14291 | 14301 | 14311 |
| Chain length 3 m | 14282 | 14292 | 14302 | 14312 |
| Chain length 4 m | 14283 | 14293 | 14303 | 14313 |
| Chain length 5 m | 14284 | 14294 | 14304 | 14314 |
| Chain length 6 m | 14285 | 14295 | 14305 | 14315 |
| Chain length 8 m | 14286 | 14296 | 14306 | 14316 |
| Chain length 10 m | 14287 | 14297 | 14307 | 14317 |
| Chain length 12 m | 14288 | 14298 | 14308 | 14318 |
| Model | HS-0.5A | HS-1A | HA-1.5A | HS-2A |
| Rated Load (KN) | 5 | 10 | 15 | 20 |
| Min. Distance between Hooks (mm) | 280 | 320 | 390 | 410 |
| Item No. | Chain length 3 m | 14321 | 14331 | 14341 | 14351 |
| Chain length 4 m | 14322 | 14332 | 14342 | 14352 |
| Chain length 5 m | 14323 | 14333 | 14343 | 14353 |
| Chain length 6 m | 14324 | 14334 | 14344 | 14354 |
| Chain length 8 m | 14325 | 14335 | 14345 | 14355 |
| Chain length 10 m | 14326 | 14336 | 14346 | 14356 |
| Chain length 12 m | 14327 | 14337 | 14347 | 14357 |
| Model | HS-3A | HS-5A | HA-10A | HS-20A |
| Rated Load (KN) | 30 | 50 | 100 | 200 |
| Min. Distance between Hooks (mm) | 485 | 600 | 820 | 1040 |
Package
1. The equipment and tools will be loaded in plywood case.
2. It also can be packed in steel frame case or wooden case.
