Product Description:
Transmission Stringing Blocks are a type of overhead conductor
block designed for the stringing of overhead conductors. These
blocks are made of high-quality materials, such as aluminum alloy
and steel, making them highly durable and able to withstand the
harsh environment of transmission lines. These blocks have a sheave
diameter of 660*560*110mm and can hold weights ranging from 30kg to
200kg. The traction force of these blocks range from 20kN to 75kN
and they have a sheave width of 110mm with a sheave number of 1 to
7, making them perfect for any overhead transmission line.
Stringing pulley blocks, transmission connector blocks, and
overhead conductor blocks are all part of our offering of
transmission stringing blocks, which are sure to provide a secure
and reliable connection of overhead conductors.
| Item Number | Model | Number of Sheave | Rated Load (kN) | Weight (kg) | Features |
| 10121 | SHD660 | 1 | 20 | 30 | Rubber coated aluminum sheave |
| 10122 | SHS660 | 3 | 40 | 106 | Middle: cast steel sheave with the width of 90mm Conductor: rubber
coated aluminum sheave |
| 10123 | SHW660 | 5 | 60 | 150 |
| 10124 | SHDN660 | 1 | 20 | 24 | MC nylon sheave |
| 10125 | SHSLN660 | 3 | 40 | 92 | Middle: MC nylon sheave Conductor: rubber coated aluminum sheave |
| 10126 | SHWLN660 | 5 | 60 | 120 |
| 10127 | SHSQN660 | 3 | 40 | 76 | MC nylon sheave |
| 10128 | SHWQN660 | 5 | 60 | 110 |
| 10129 | SHQZ660 | 7 | 80 | 268 | Middle: cast steel sheave Conductor: rubber coated aluminum sheave |
| 10130 | SHQ660A | 7 | 75 | 190 | Middle: cast steel sheave Conductor: MC nylon sheave |
Features:
These products are made of top MC Nylon with 8# steel and highly
galvanized frame. They are also installed with imported bearings.
The material used is from USA and is composed of 96% pure raw
material and colored polyurethane material. These products are
available in four color - red, blue, yellow and green which are
highly attractive.
Technical Parameters:
| Parameters | Details |
|---|
| Product Name | Transmission Stringing Blocks |
| Material | MC Nylon/Aluminum Alloy/Cast Steel |
| Capacity | 50kN-200kN |
| Weight | 30kg-200kg |
| Sheave Number | 1-7 |
| Warranty | 1 Year |
| Traction Force | 20kN-75kN |
| Sheave Width | 110mm |
| Sheave Diameter | 660*560*110mm |
Applications:
This 660mm MC nylon sheave of the Stringing Block is suitable for
ACSR500 overhead line conductor stringing works. It can take up to
a maximum of 500 ACSR conductors.
ACSR conductor is a kind of specific conductor renowned for a good
combination of strength and electrical conductivity. That makes it
an ideal choice for overhead line stringing works.
Customization:
Customized Service for Transmission Stringing Blocks
- Brand Name: Lingkai
- Model Number: SHD,SHDN,SHSQN,SHWQN,SHSLN,SHWLN
- Place of Origin: NINGBO
- Certification: ISO CE
- Minimum Order Quantity: 50
- Price: Get the latest
- Packaging Details: Containers
- Delivery Time: 5-20days
- Payment Terms: T/T L/C
- Supply Ability: 1000 sets one month
- Product Name: Transmission Stringing Blocks
- Material: MC Nylon/Aluminum Alloy/Cast Steel
- Sheave Width: 110mm
- Sheave Number: 1-7
- Capacity: 50kN-200kN
Our Transmission Connector Blocks are widely used in Transmission Line Blocks, Transmission Line Stringing Blocks and Transmission Line Block applications. They are made of high quality MC Nylon/Aluminum Alloy/Cast Steel for long lasting durability.
Support and Services:
We provide technical support and service for our Transmission
Stringing Blocks. Our team of experienced professionals is
available to answer any technical questions and provide assistance
with product installation and maintenance.
We offer online and telephone assistance for customers who need
help troubleshooting their products. Our technical support team is
available to provide helpful advice and guidance on product usage
and maintenance. We also provide detailed product documentation to
help customers understand the features and functions of our
Transmission Stringing Blocks.
We have a network of authorized service centers that are equipped
to handle repairs and warranty service for our products. Our
service centers are staffed with highly trained technicians and are
capable of providing quality service and quick turnaround times.
We strive to provide the highest level of customer service and
satisfaction. If you have any questions or need assistance with our
Transmission Stringing Blocks, please contact us.
