Product Description:
Our Transmission Stringing Blocks are specifically designed for use
in the transmission line industry. Made from high quality MC
Nylon/Aluminum Alloy/Cast Steel, these blocks are built to last.
With a traction force of up to 75kN, these blocks can handle the
toughest conditions. The product name is Transmission Stringing
Blocks and the sheave width is 110mm, making them suitable for a
variety of applications. Furthermore, they come with a 1 year
warranty, so you can be sure that you're getting a reliable
product. So if you need transmission connector blocks, transmission
line blocks, or transmission line blocks, then our Transmission
Stringing Blocks are the perfect choice.
Features:
Our products are fabricated with the top MC Nylon made of 96% pure
raw material from USA. Moreover, 8# steel and highly galvanzied
frame are added on to imported bearings. We are guaranteeed with
the ISO, UL and Certificate from the renowned authoritative service
supplier.
| Item Number | Model | Number of Sheave | Rated Load (kN) | Weight (kg) | Features |
| 10121 | SHD660 | 1 | 20 | 30 | Rubber coated aluminum sheave |
| 10122 | SHS660 | 3 | 40 | 106 | Middle: cast steel sheave with the width of 90mm Conductor: rubber
coated aluminum sheave |
| 10123 | SHW660 | 5 | 60 | 150 |
| 10124 | SHDN660 | 1 | 20 | 24 | MC nylon sheave |
| 10125 | SHSLN660 | 3 | 40 | 92 | Middle: MC nylon sheave Conductor: rubber coated aluminum sheave |
| 10126 | SHWLN660 | 5 | 60 | 120 |
| 10127 | SHSQN660 | 3 | 40 | 76 | MC nylon sheave |
| 10128 | SHWQN660 | 5 | 60 | 110 |
| 10129 | SHQZ660 | 7 | 80 | 268 | Middle: cast steel sheave Conductor: rubber coated aluminum sheave |
| 10130 | SHQ660A | 7 | 75 | 190 | Middle: cast steel sheave Conductor: MC nylon sheave |
Technical Parameters:
| Parameter | Value |
|---|
| Product Name | Transmission Stringing Blocks |
| Sheave Diameter | 660*560*110mm |
| Sheave Number | 1-7 |
| Weight | 30kg-200kg |
| Warranty | 1 Year |
| Sheave Width | 110mm |
| Capacity | 50kN-200kN |
| Material | MC Nylon/Aluminum Alloy/Cast Steel |
| Traction Force | 20kN-75kN |
Applications:
The 660mm MC nylon sheave of the stringing block is designed for
overhead line conductor stringing. It has the ability to hold a
maximum suitable conductor of ACSR630.
The ACSR630 is a kink-resistant, galvanized-steel wire that is
constructed from concentric-lay-stranded aluminum and steel. It is
regularly used for transmission and distribution lines.
Customization:
Lingkai Transmission Stringing Blocks
- Brand Name: Lingkai
- Model Number: SHD, SHDN, SHSQN, SHWQN, SHSLN, SHWLN
- Place of Origin: NINGBO
- Certification: ISO CE
- Minimum Order Quantity: 50
- Price: Get the latest
- Packaging Details: Containers
- Delivery Time: 5-20days
- Payment Terms: T/T L/C
- Supply Ability: 1000 sets one month
- Product Name: Transmission Stringing Blocks
- Capacity: 50kN-200kN
- Sheave Diameter: 660*560*110mm
- Sheave Width: 110mm
- Traction Force: 20kN-75kN
Lingkai Transmission Line Blocks, Transmission Connector Blocks,
Transmission Line Blocks Connector
Lingkai Transmission Stringing Blocks are certified by ISO CE, and
with a minimum order quantity of 50. We can deliver in 5-20days
after payment. The capacity is from 50kN-200kN, the sheave diameter
is 660*560*110mm, and the traction force is 20kN-75kN. We can
provide 1000 sets a month.
Support and Services:
We provide comprehensive technical support and service for our
Transmission Stringing Blocks product. Our experienced engineers
and technicians are available to help you with any technical
questions or problems you may have. We can provide assistance with
installation, operation, maintenance, troubleshooting, and more.
We also offer a range of on-site and online training sessions to
help you get the most out of your product. Our knowledgeable
trainers can provide instruction on safety, proper use, and general
product knowledge.
If you ever need any help, please do not hesitate to contact us. We
are here to help you get the most out of your product.
